  #11
Old 10-06-2016, 08:52 PM
jcm0791's Avatar
jcm0791 jcm0791 is offline
Super awesome fantastic!

Join Date: Jul 2010
Posts: 1,852
Default

Discovering this made the need for new wheels a little more pressing.



Which was fine because there really wasn't room for the bigger brakes in the 16" wheels.

Before:


After:





And hiding in an RPF1 ... 17"



An the rear:




The 17x9 fit well in the front but the rear required a bit of a pull for the 17x10 but for fun, I decided to bolt the 17x10 with a 295 35 17 onto the front and see how close it is.



... close, but no cigar. Gonna need some wider fenders before that happens.

Picture with the 17s:

Reply With Quote
  #12
Old 10-06-2016, 10:05 PM
chrenan's Avatar
chrenan chrenan is offline
Super Moderator

Join Date: Feb 2011
Posts: 1,112
Default

Is that a common failure of the factory rim? Heat or pothole related? That's nuts.
__________________
1987 951 - M193 Version for Japan

Full course: 70.467Eddie's S: 73.39

2015 Jeep Wrangler
2009 Subaru Impreza
2005 Chevy 2500 HD
Reply With Quote
  #13
Old 10-06-2016, 10:10 PM
GrantC's Avatar
GrantC GrantC is offline
Super awesome fantastic!

Join Date: Apr 2010
Location: Behind the wheel, behind the camera.
Posts: 1,040
Default

Quote:
Originally Posted by chrenan View Post
Is that a common failure of the factory rim? Heat or pothole related? That's nuts.
It's common enough that I've heard of it before. If I recall right, there are 2 versions of those FD rims. Thin & thick spokes?

They're like the R32 GTR wheels in that they're one of the few 16x8" 5x114.3 options around.
__________________
-- facebook -- flickr -- S2k auto-x build -- Former WRX Auto-x Build --

Quote:
Originally Posted by ThomasChichak View Post
the neon is my dream race car
Reply With Quote
  #14
Old 10-07-2016, 12:01 AM
jcm0791's Avatar
jcm0791 jcm0791 is offline
Super awesome fantastic!

Join Date: Jul 2010
Posts: 1,852
Default

Quote:
Originally Posted by GrantC View Post
It's common enough that I've heard of it before. If I recall right, there are 2 versions of those FD rims. Thin & thick spokes?

They're like the R32 GTR wheels in that they're one of the few 16x8" 5x114.3 options around.
Yes, the first year seem to be the effected ones. My car came with 6 wheels (4 original thin, 2 later thick)
Reply With Quote
  #15
Old 10-08-2016, 04:34 PM
jcm0791's Avatar
jcm0791 jcm0791 is offline
Super awesome fantastic!

Join Date: Jul 2010
Posts: 1,852
Default

This is the way that the Hinson conversion arrived:



With a tall radiator and an AEM style intake that went all the way down into the front loweee valence ... Like so many cold air intakes, that I hate, it had a lot of bends and puny little filter in the end.
Reply With Quote
  #16
Old 10-09-2016, 03:36 AM
jcm0791's Avatar
jcm0791 jcm0791 is offline
Super awesome fantastic!

Join Date: Jul 2010
Posts: 1,852
Default

After the first season the original radiator developed a small leak from the core. I was never a fan of the radiator/airfilter setup Hinson supplied ... it worked fine, but it was not esthetically pleasing to me.

This did give me opportunity to install this:



Funny that Mishimoto, in Japan, makes a rad to fit an LS swapped car, but not for a rotary powered one.

Moving the radiator back to the factory location meant that the Hinson air intake wouldn't work either ... which suited me fine.

The Mishimoto rad came with a filler neck that was lower than the top rad hose ... which seemed dumb... so I capped it off and fabricated a swirl pot in the upper rad hose and added some air bleed lines from the top of the rad, top of the swirl pot, and the top of the cylinder heads. These vent lines are run to an expansion tank mounted to the front of the cylinder head. Shown here, along with fabrication of an air box to fit the new K&N:

Reply With Quote
  #17
Old 10-09-2016, 05:14 AM
jcm0791's Avatar
jcm0791 jcm0791 is offline
Super awesome fantastic!

Join Date: Jul 2010
Posts: 1,852
Default

More photos of the new rad going in and the new airbox being completed. Here pictured with the OEM MAF.








There was also some requiring that went on. Under the hood, all of the rotary engine wiring was removed and under the dash, most of the wire you can see here is gone now. In all, about 35lbs of wiring was removed along with the complete air conditioning system.


Reply With Quote
  #18
Old 10-09-2016, 05:19 PM
jcm0791's Avatar
jcm0791 jcm0791 is offline
Super awesome fantastic!

Join Date: Jul 2010
Posts: 1,852
Default

All together with the Lingenfelter 100mm MAF ... up from the factory 65ish mm.

Reply With Quote
  #19
Old 10-16-2016, 03:39 PM
jcm0791's Avatar
jcm0791 jcm0791 is offline
Super awesome fantastic!

Join Date: Jul 2010
Posts: 1,852
Default

And then there was the time I broke the diff ... ironically, on the street.



Reply With Quote
  #20
Old 10-17-2016, 05:50 AM
matt matt is offline
Slow

Join Date: Jul 2008
Location: Edmonton
Posts: 3,156
Send a message via ICQ to matt Send a message via AIM to matt Send a message via MSN to matt
Default

You never do anything half-assed!
__________________
Potatos.
Reply With Quote
